1. Cleware Usb Switch Download
2. Cleware Usb Switch Adapter

• 8 heavy duty power relays, each connected to 3 pin plug connectors to access opening and closing contacts
• 3 A @ 30 V maximum at each relay
• every relais is electrically insulated from each other
• Availble mounted in a housing with pin plug sockets os as PCB with clamps
• API for easy integration in user applications
• The control softwareClewareControlfortimedswitching,USBswitchlieswitha graphical user interfaceandUSBswitchCmdfor switchingvia commandinvocationfor download
• Any switch could be controlled by programmed timer with up to 256 switch points
• No driver installation needed with Windows® Operating Systems since Windows® 2K
  (® Microsoft Windows is a registered trademark of the Microsoft Corporation.)
• Application Program Interface for easy integration in user applications
• Linux support available.
• Use with LabView® possible
• RoHS, CE & EN60950 conform/ IP30
• USB connector, cable length see options
• Every device shows up with a unique serial number, so several of these devices could be used with one PC
• For indoor use only
• 4 years warranty
• Made in Germany
• More infos at USB-Switch 8

Cleware Usb Switch Download

• PC-controlled mains switch equipped with german Schuko mains plug and socket
• Switches 230V / 16 A, max 3,500 W (single phase motor rating max. 550 W) using extrem reliable Finder®-Relais
• Multiple USB-Switches at a single PC controlled by the serial number
• Special version ATXX available which turns on with the PC
• The control softwareClewareControlfortimedswitching,USBswitchlieswitha graphical user interfaceandUSBswitchCmdfor switchingvia commandinvocationfor download
• The control softwareClewareControlfortimedswitching,USBswitchwitha graphical user interfaceandUSBswitchCmdfor switchingviacommand callisready for download.
• No driver installation needed with Windows® x86/x64 variants. (® Microsoft Windows is a registered trademark of the Microsoft Corporation.)
• Application Program Interface for easy integration in user applikations
• Linux support now available.
• Use with LabView® possible
• RoHS, CE & EN60950 conform/ IP20
• About 120 mA power consumption when turned on
• USB cable length see cable length option
• For indoor use only
• 4 years warranty
• Made in Germany
• more info are available at USB-Switch

Cleware Usb Switch Adapter

Multiple USB-Switches at a single PC controlled by unique the serial number The control software ClewareControl for timed switching, USBswitch lies with a graphical user interface and USBswitchCmd for switching via command invocation for download Any switch could be controlled by programmed timer with up to 256 switch points. Currently, only the 'USB-SwitchC IEC' device is supported. This provides a single IEC connector to switch a single PSU input. The Cleware USB Device can be purchased from the manufacturer at this link. When configuring, you should select 'Opening' (as in, the relay is normally closed - without being told otherwise it is allowing power through) and 'Mechanical'.
